CEMENTED RESTORATION SOLUTIONS
These abutments, which are preferred in traditional implant prosthetic approaches, provide solutions for indications such as single crowns, bridges, and total prosthetic restorations. Alternative designs such as Profile Abutment, Dual Abutment, Aesthetic Abutment, 15/25° Angled Aesthetic Abutment, give the user the most accurate functional use aesthetically based on the position of the implant and the relationship between bone – soft tissue – crown.
PROFILE ABUTMENT
| Platform | NP | RP | ||
| Implant Ø | Ø3.3 mm | Ø3.7 mm | Ø4.1 mm | Ø4.7 mm |
| Profile Ø | Ø4.5 mm | Ø5.5 mm | ||
| H: 1.0 mm | 02.10.10.10 | 02.10.20.10 | ||
| H: 2.0 mm | 02.10.10.20 | 02.10.20.20 | ||
| H: 3.0 mm | 02.10.10.30 | 02.10.20.30 | ||
Can be used for the fixed restorations of single crowns, bridges or cases with complete edentulism. It is easy to adapt to the desired site aesthetically by preparation.
DUAL ABUTMENT
| Platform | NP | RP | ||
| Implant Ø | Ø3.3 mm | Ø3.7 mm | Ø4.1 mm | Ø4.7 mm |
| Profile Ø | Ø4.0 mm | Ø5.0 mm | ||
| H: 0.5 mm | 02.01.40.05 | 02.01.50.05 | ||
| H: 1.0 mm | 02.01.40.10 | 02.01.50.10 | ||
| H: 2.0 mm | 02.01.40.20 | 02.01.50.20 | ||
| H: 3.0 mm | 02.01.40.30 | 02.01.50.30 | ||
| H: 4.0 mm | 02.01.40.40 | 02.01.50.40 | ||
Can be used for the fixed restorations of single crowns, bridges, or cases with complete edentulism. There are many alternatives for gingival height, shoulder, and body width in order to obtain aesthetic and functional results quickly and save time for the technician and dentist. Can be prepared if the interocclusal space is insufficient.
AESTHETIC ABUTMENT
| Platform | NP | RP | ||
| Implant Ø | Ø3.3 mm | Ø3.7 mm | Ø4.1 mm | Ø4.7 mm |
| Profile Ø | Ø4.0 mm | Ø5.0 mm | ||
| H: 1.0 mm | 02.04.10.10 | 02.04.20.10 | ||
| H: 2.0 mm | 02.04.10.20 | 02.04.20.20 | ||
| H: 3.0 mm | 02.04.10.30 | 02.04.20.30 | ||
Its form imitates the anatomical structure of the gingiva in the anterior zone, where aesthetic expectations are at a maximum level. It offers fast and aesthetically-oriented solutions to its users that would meet their expectations.
15° AESTHETIC ABUTMENT
| Platform | NP | RP | ||
| Implant Ø | Ø3.3 mm | Ø3.7 mm | Ø4.1 mm | Ø4.7 mm |
| H: 1.0 mm | 02.02.10.10 | 02.02.20.10 | ||
| H: 2.0 mm | 02.02.10.20 | 02.02.20.20 | ||
| H: 3.0 mm | 02.02.10.30 | 02.02.20.30 | ||
| H: 4.0 mm | 02.02.10.40 | 02.02.20.40 | ||
Offers a wide selection of angled 15° and 25° designs and different gingival heights. Its aesthetic form imitating the gingival anatomy provides an excellent soft-tissue relationship. Thanks to its octagonal connection design, it allows the dentist to load in 8 different positions at a 45° angle.
25° AESTHETIC ABUTMENT
| Platform | NP | RP | ||
| Implant Ø | Ø3.3 mm | Ø3.7 mm | Ø4.1 mm | Ø4.7 mm |
| H: 1.0 mm | 02.03.10.10 | 02.03.20.10 | ||
| H: 2.0 mm | 02.03.10.20 | 02.03.20.20 | ||
| H: 3.0 mm | 02.03.10.30 | 02.03.20.30 | ||
| H: 4.0 mm | 02.03.10.40 | 02.03.20.40 | ||
Offers a wide selection of angled 15° and 25° designs and different gingival heights. Its aesthetic form imitating the gingival anatomy provides an excellent soft-tissue relationship. Thanks to its octagonal connection design, it allows the dentist to load in 8 different positions at a 45° angle.
These abutments, which are preferred in traditional implant prosthetic approaches, provide solutions for indications such as single crowns, bridges, and total prosthetic restorations. Alternative designs such as Profile Abutment, Dual Abutment, Aesthetic Abutment, 15/25 ° Angled Aesthetic Abutment, give the user the most accurate functional use aesthetically based on the position of the implant and the relationship between bone – soft tissue – crown.
